Thank you for choosing the Growatt ALP 5.0L-E1-AU battery. To ensure a smooth and safe installation, please follow the steps below.
Installation Overview
1. Preparation
Before starting, ensure you have the necessary tools:
✔ 5mm Allen key
✔ Screwdriver
✔ Wrench
✔ Measuring tape
✔ Multimeter
✔ Impact drill
✔ Marker
2. Installation Requirements
- Floor Installation: Ensure the floor is level and do not turn the battery upside down.
- Wall Installation: Do not install more than five battery modules per line. The wall must support at least 280kg.
- Outdoor Installation: Provide protection from direct sunlight and rain.
3. Mounting the Battery
- Mark the hole positions for the installation.
- Drill and secure the expansion bolts.
- Install the wall bracket and mount the battery.
- Secure the modules using anti-tipping plates.
4. Electrical Connection
- Connect the positive and negative power cables securely.
- Ground the battery properly for safety.
- Use parallel cables if installing multiple battery packs.
5. Powering On
- Connect the battery to the PCS (Power Conversion System).
- Turn on the circuit breaker.
- Press the POWER button for 3 seconds until the LED indicators light up.
Important Safety Notes
⚠ Do not install the battery while powered on. Ensure all RUN lights are off before installation.
⚠ Always connect the ground cable for safety.
⚠ If using multiple battery packs, follow the correct parallel wiring method.
For detailed instructions and diagrams, please download the full Quick Installation Guide below.
📎 Download Here
If you need assistance, contact australia@growatt.com or visit https://au.growatt.com.
