We appreciate your trust in our products and are committed to providing you with the best support for a seamless experience. To assist you with the installation and setup of your APX5.0_30.0P-S0 system, we have attached a Quick Installation Guide that contains essential instructions and safety precautions.
How to Use the Attached Guide
- Download the attached PDF and save it on your device for easy reference.
- Carefully read the installation and safety instructions before starting the setup process.
- Follow the step-by-step guide to ensure a smooth installation while avoiding any potential issues.
- Pay special attention to important safety warnings, as outlined below.
Key Safety Reminders (From the Installation Manual)
- Do not install a DC circuit breaker between the battery system and the PCS unless it meets the required specifications (rated working voltage >600V, rated working current >63A).
- If using a DC circuit breaker, do not operate it while powered on to avoid damage to the machine.
- Ensure that the PE cable is securely connected.
- Before performing maintenance or repairs:
- Turn off the AC circuit breaker and PV switch of the PCS, as well as the APX switch.
- Wait at least 15 minutes after shutting down the system.
- Ensure the GROWATT logo indicator on the APX is off before proceeding.
- Multiple battery systems in parallel: Only one module’s start key needs to be pressed to start the system.
- This product cannot be powered on using AC power from the grid directly.
- Monitoring information is uploaded via a data logger connected to the inverter—refer to the data logger’s User Manual for details.
For further details, please download the attached Quick Installation Guide and refer to the instructions inside. If you have any questions, feel free to contact our support team at australia@growatt.com or visit our website at https://au.growatt.com.
Thank you for choosing Growatt!
